Aerobar Extensions Grips (Style)
Aerobar Extensions Grips (Dicipline)

Designed to meet the rigorous demands of competitive road time trial racing and track disciplines, these Aerobar Extensions deliver precision adjustability and rider comfort while maintaining the aerodynamic efficiency serious athletes demand.

Designed to integrate seamlessly with the Velobike Adjustable Riser System, these extensions also feature a universal 22.2mm pole standard to suit a wide range of 3rd party aerobar mounting systems.

The extensions have built in design features to help fine-tune your position through:

  • Fore/aft adjustment via integrated spacers
  • Rotational adjustment through the cylindrical mounting system
  • Modular ergonomic grips for athlete specific comfort
  • Integrated blip compatibility for road configuration

Geometry

Grip Variants

Grip A: Symmetrical grip for general endurance use
Grip B: Similar to Grip A, with a 20 degree inward leaning angle
Grip C: A sculpted grip shape that hugs the shape of the palm

Unsure on what grip shape to choose? Grip C is the most popular choice for the majority of athletes

Track: No electronic shifter compatibility
Shimano Di2:
Compatible with Shimano Di2 Remote Shifters (SW-R9150)
SRAM Blip:
Compatible with SRAM eTap AXS Wireless Blip Shifters (EC-BLIP-B1)

More grip shapes are in development. Custom grip shapes are available on request.

Self made grips or grips made by 3rd parties will not be UCI legal due to not being tested against the ISO safety regulations.

Technical Specifications
  • Interchangeable grip system
  • Material: Gloss Carbon Fiber
  • Compatibility: Universal 22.2mm tube mounting
  • Tested in accordance to ISO 4210-5:2023
What's In The Box
  • 2x Extensions (Left & Right)
  • 2x Grips (of your choice)
  • 2x M6 Grip Mounting Hardware
  • 2x 5mm Spacers
  • 2x 10mm Spacers
  • 2x 20mm Spacers
  • 2x Adjustable Riser Blend Spacer
Spare Parts & Extra Accessories

Extra Aerobar Extension Grips are available individually.

For the complete cockpit setup, see the Aerobar Cockpit System.

Installation Tips
  • 22.2mm tubes may need to be cut to achieve your desired fit.
  • For optimal security, we recommend using Loctite 243 on all fastenings.
